Description
Performance
- ISO class 4 (US class 10) HEPA filter for optimal protection against cross-contamination.
- 0.3 μm and larger particulates are removed with 99.99% efficiency, leak-tight HEPA filter which satisfying class 10.
(US Federal Standard 209E)
(average life span of HEPA filter: 3 years – it depends on the test room conditions) (optional) - High-quality polyester fiber pre filter (with minimal pressure loss and 85% arrestant on the A.F.I. test) for trapping larger particles and increasing the life of the main HEPA filter.
- Exclusive diffusing muffler structure forms high quality laminar flow.
- Quiet and comfortable working environment. (less than 65dB)
Convenience
- Built-in differential pressure gauge for easy checking HEPA filter condition.
- Comfortable front access to cartridge type of filters for easy replacement.
- Easy blower speed adjustment by the control panel.
- Highly durable, rust-free, and easy-to-clean grade 304 stainless steel work surface.
- The inner left side magnetic board allows some memos and small tools.
Safety
- UV-blocking and impact-resistant tempered glass door.
- If the sash is opened during UV-lamp operation, UV lamp automatically turns off to protect users.
- Lighting mode selection by 3-position toggle switch (UV / off / fluorescent) preventing harmful UV exposure.
- Smoothly sliding front door stoppable at any height for user’s safety and easy transport of equipment into the workspace.
- Protection against over-current.
Specifications
- Air flow type: Vertical laminar flow
- Air volume (minimum / maximum): 0 to 1020 cmh / 0 to 600 cfm
- Laminar airflow velocity: 0.3 m/s / 59 fpm
- Air cleanliness within work space: ISO 14644-1 class 4, US Federal Standard 209E class 10
- HEPA filter
- Typical efficiency of 99.99% on 0.3㎛ (US MIL-STD-282)
- Micro glass fiber media, particle board, AL separator, neoprene gaskets
- Pre filter
- Polyester fibers with a filter efficiency of 85% (A·F·I TEST)
- Aluminum frame, polyester fiber media
- Noise level: Typically < 65 dB at blower speed
- Materials
- Main body: Steel powder coating
- Work surface: Stainless steel, grade 304, brushed finish
- Windows (front / side): Colorless and transparent UV absorbing 5 mm tempered glass
- Illumination
- Intensity: > 650 lux
- Fluorescent lamp: 30 W × 2ea
- Electronically ballasted fluorescent lamp
- UV lamp: 25 W × 1ea
- Electronically ballasted UV lamp
- Electric socket outlets: 230V socket
