Description
Structural Functional Features
- Best space-efficient model with double stacking.
- Up to 80°C, 500rpm enables setting of various experimental conditions.
- Utilized as an incubator using the shelves.
- Three operating modes: Temperature & Shaking, Temperature, or Shaking.
- Includes internal power outlet.
- Shaking structure with minimized vibration.
Use Convenience Features
- Accurate rpm and temperature control through temperature auto-tuning / microprocessor PID and calibration.
- Monitor via mobile app anytime, anywhere with LC Connected. (mobile monitoring system)
(when purchased LC GreenBox) - Countdown timer (999 hours 59 minutes) of shaking operation.
- Intuitive operation with color touch display.
- High brightness / low-power LED illumination makes it easy to observe inside.
- Spill drain port for internal cleanliness and easy maintenance.
Outstanding Safety
- Electronic over temperature protection system.
(advanced over temperature (A-OT) limiter)
Independent precision temperature sensor and controller provides more secure and reliable over temperature protection. - Conventional over-temperature protection system.
(B-OT, backup over temperature limiter)
A backup device against electronic system failure, mechanically preventing over temperature even when there are electronic errors. - Soft start and stop shaking function.
- Malfunction prevented by controller lock function.
- Displays all information such as device operation and error occurrence.
- Overcurrent protection device restricts operation when objects are caught inside the system and shaking is not possible.
Smart Self-diagnosis
- Real-time self-diagnostics to check equipment for abnormal conditions.
- Alarm is generated by monitoring difference between actual rpm/temperature and set rpm/temperature.
- Automatic rpm adjustment when device instability occurs.
(high rpm, overload, weight imbalance, etc.) - Detects abnormal conditions relating to the platform on which the sample is placed and stops the operation.
- Automatic restart as it was operated after power recovery.
Specifications
- Dimensions 36 × 26 × 42 in
- Temperature
- Range (℃ / ℉) Amb. +5 to 80 / Amb. +9 to 176
- Fluctuation at 37℃ (±℃ / ℉) in flask 0.1 / 0.18
- Variation at 37℃ (±℃ / ℉) in flask 0.5 / 0.90
- Refrigerator (Hp) –
- Shaking system
- Motion type Orbital
- Speed range (rpm) 20 to 500
- (stackable : 20 to 250)
- Max. speed per permissible load (rpm) 500 (max. 10 kg / 22.0 Ibs)
- 400 (max. 15 kg / 33.1 Ibs)
- 250 (max. 15 kg / 33.1 Ibs) – Stacked
- Amplitude size (mm / inch, dia.) 19.1 / 0.75
- Speed stability2) (rpm, %) ±1
- Timer (count-down) 999 hr 59 min.
- Dimension
- Chamber volume (L / cu ft) 80 / 2.8
- Platform (W x D, mm / inch) 350 x 350 / 13.8 x 13.8
- Interior (W x D x H, mm / inch) 440 x 440 x 418 / 17.3 x 17.3×16.5
- Exterior (W x D x H, mm / inch) 578 x 815 x 854 / 22.8 x 32.1 x 33.6
- Quantity of shelves (standard/max.) 2 / 8
- Net weight (Kg / lbs) 153 / 337.3
- Electrical requirements (120V, A) 60Hz, 9.5
