Description
Structural Functional Features
- Large-capacity triple stackable incubated shaker.
- Up to 80°C, 400rpm enables experimental conditions for various applications.
- Three operating modes: Temperature & Shaking, Temperature, or Shaking.
- Shaking structure with minimized vibration.
- Convenient to change samples with glide-up door.
- Stable shaking of high-load samples. (patent registered: 10-1678160)
Use Convenience Features
- Accurate rpm and temperature control through temperature autotuning / microprocessor PID and calibration.
- Monitor via mobile app anytime, anywhere with LC Connected.
(mobile monitoring system) (when purchased LC GreenBox) - Countdown timer (999 hours 59 minutes) of shaking operation.
- Intuitive operation with color touch display.
- High brightness / low-power LED illumination makes it easy to observe inside.
- Spill drain port for internal cleanliness and easy maintenance.
- Stand with adjustable feet to ensure a level installation, and retractable casters to allow positioning prior to installation.
(Retractable Foot Caster)
Outstanding Safety
- Electronic over temperature protection system.
(A-OT, advanced over temperature limiter)
Independent precision temperature sensor and controller provides more secure and reliable over temperature protection. - Conventional over-temperature protection system.
(B-OT, backup over temperature limiter)
A backup device against electronic system failure, mechanically preventing over temperature even when there are electronic errors. - Soft start and stop shaking function.
- Malfunction prevented by controller lock function.
- Displays all information such as device operation and error occurrence.
- Overcurrent protection device restricts operation when objects are caught inside the system and shaking is not possible.
Smart Self-diagnosis
- Real-time self-diagnostics to check equipment for abnormal conditions.
- Alarm is generated by monitoring difference between actual rpm/temperature and set rpm/temperature.
- Automatic rpm adjustment when device instability occurs.
(high rpm, overload, weight imbalance, etc.) - Detects abnormal conditions relating to the platform on which the sample is placed and stops the operation.
- Automatic restart as it was operated after power recovery.
-
Specifications
- Dimensions 49 × 55 × 84 in
- Temperature
- Range (℃ / ℉) Amb. +10 to 80 / Amb. +18 to 176
- Fluctuation at 37℃ (±℃ / ℉) in flask 0.1 / 0.18
- Variation at 37℃ (±℃ / ℉) in flask 0.6 / 1.08
- Refrigerator (Hp) –
- Shaking system
- Motion type Orbital
- Speed range (rpm) 30 to 400 (stackable : 30 to 250)
- Max. speed per permissible load (rpm) 1 unit only
- 400 (max. 20 kg / 44.1 Ibs)Stacked units
- 250 (max. 15 kg / 33.1 Ibs)
- 200 (max. 20 kg / 44.1 Ibs)
- Amplitude size (mm / inch, dia.) 25.4 / 1
- Speed stability2) (rpm, %) ±1
- Timer (count-down) 999 hr 59 min.
- Dimension (1 unit)
- Chamber volume (L / cu ft) 198 / 7.0
- Platform (W x D, mm / inch) 755 x 520 / 29.7 x 20.5
- Interior (W x D x H, mm / inch) 809 x 624 x 393 / 31.9 x 24.6 x 15.5
- Exterior (W x D x H, mm / inch) 1 unit ; 1307 x 996 x 755 / 51.5 x 39.2 x 29.7
- 1 unit+stand-I or 2 units stacked ; 1307 x 996 x 1355 / 51.5 x 39.2 x 53.3
- 2 units+stand-II stacked ; 1307 x 996 x 1655 / 51.5 x 39.2 x 65.2
- 3 units stacked ; 1307 x 996 x 1955 / 51.5 x 39.2 x 77.0
- Net weight (Kg / lbs) 300 / 661.4
- Electrical requirements (120V, A) 60Hz, 7.1
