Description
Structural Functional Features
- Built-in fluorescent lamp makes it easy to see inside.
- Compact design makes installation and movement convenient.
- VFD display allows for easy checking of operation status.
Use Convenience Features
- Convenient handling of equipment due to convenient front opening.
- Three sizes of models according to the cabinet size.
- Digital-type UV timer function.
(up to 59 minutes and 59 seconds)
Outstanding Safety
- Block UV 99.9% on the front/ left / right side with acrylic material.
- When the door is opened, the UV light is turned off automatically to protect the user and the fluorescent lamp is operated, making it convenient to use.
- Protection from overcurrent.
Specifications
- Weight 63 lbs
- Dimensions 23 × 21 × 31 in
- Illumination
U.V. Density (μW/cm2) 300 ± 10%
U.V. lamp (254 nm, W) 8
Fluorescent lamp (W) 8
Fluorescent lamp intensity (Lux) more than 800 - Material
Window (Front, Sides, Rear) Acryl (Clear)
Window (Rear) Powder coated steel
U.V. protection 99.90%
Working table Stainless steel - Dimensions
Exterior (W x D x H, mm / inch) 450 x 509 x 610 / 17.7 x 20 x 24
Interior (W x D x H, mm / inch) 433 x 500 x 468 / 17.0 x 19.7 x 18.4
Net weight (kg / lbs) 15 / 33.1 - Electrical requirements (120V, 1ph) 60Hz, 0.2A
