Description
Safety at all times: High-end functions for the protection of cell cultures, bacteria cultures or tissue cultures.
Features:
- Working-temperature range: 5 °C above ambient temperature up to +50 °C Standard sterilization program: 60 minutes at 180°C (without removing the sensors)
- Setting temperature range +18 to +50 °C
- Setting accuracy temperature: 0.1 °C
- Temperature sensor: 2 Pt100 sensors DIN Class A in 4-wire-circuit for mutual monitoring, taking over functions in case of an
error - Temperature variation in chamber: at 37 °C (to DIN 12880:2007-05) +/- 0.3 °C
- Temperature fluctuations with time: at 37 °C (to DIN 12880:2007-05) +/- 0.1 °C
- Humidity control (standard): Humidity limitation thanks to a Peltier element; when water dish is full and inserted, the Peltier element limits the value of relative humidity in the interior to 93% rh+/-2.5%
- Setting accuracy humidity: 0.5% rh
- Humidity setting range active humidity control: Humidity supply with distilled water from external tank 40 to 97% rh and rh off
- ControlCOCKPIT: TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-color displays
- Adjustable parameters: temperature (Celsius or Fahrenheit), CO2, program time, time zones, daylight savings time
- Function Setpoint WAIT: the process time does not start until the set temperature is reached
- Language setting: German, English, Spanish, French, Polish, Czech, Hungarian
- AutoSAFETY: additionally integrated over- and under temperature monitor “ASF”, automatically following the setpoint value at a preset tolerance range, alarm in case of over- or under temperature, heating is switched off in case of overtemperature
- Autodiagnostic system: for fault analysis
- Alarm: audible and visual
Specifications:
- Dimensions w(A) x h(B) x d(C): 22” x 18.9” x 15.7”
- Interior: material 1.4301 (ASTM 304), corrosion resistant
- Volume: 107 L / 3.8 cu. Ft.
- Max. number of shelves: 6
- Max. loading of chamber: 198 lbs
- Max. loading per shelf: 33 lbs
- Electrical: 230 V(+ / – 10%, 50/60 Hz / 6.5 amps) & 115 V(+ / – 10%, 50/60 Hz / 13.0 amps)
Stainless Steel:
For many years exterior textured stainless steel has been the unmistakable feature of Memmert ovens, incubators, and climate chambers in laboratory and light-industrial settings. Memmert equipment exemplifies functional design in its most elegant and hygienic form, while still being scratch resistant, robust and durable.
Stainless steel is the ideal material for temperature control chambers and heating baths. It is particularly corrosion-resistant, hygienic, robust and recyclable without question.
Wherever Memmert ovens and heating baths are used, the superiority of high-quality stainless steel is undeniable in comparison to others that utilize coated sheet steel, which can corrode very quickly when in constant use.
For the outer housing of all Memmert appliances, textured stainless steel is used (rear walls are zinc-plated sheets). The inner chamber, sliding shelves/grids, housing, interior basin and accessories for every heating bath, stainless steel of class W-St. 1.4301 (ASTM 304) is used. Since aggressive substances are frequently used in the vacuum drying oven, the inner chamber and thermoshelves are made of stainless-steel W-St. 1.4404 (ASTM 316L), and the tubing is made of stainless-steel W-St. 1.4571 (ASTM 316i).
